Due to product launch of dual output module card, NMD-240, changes will be made to both label markings in print and DBANMP1K2 and DBANMP650 model labels that are attached on NMP1K2/650 front-ends. Changes will be implemented in two phases:

1. Phase 1, label markings in print add +, - symbols and color blocks to the right side in each bracket, from SLOT 1 to 4/6.
2. Phase 2, model labels add diagram pertaining to dual output module, indicating signal connector CN82 and tuning direction while using SVRs to adjust output voltage of +V1/+V2.


Should you have any further question, please contact your MEAN WELL sales representative.


Change in effect:

1. Since Jan. 2021
2. Running change on model labels, P/N: DBANMP1K2 and DBANMP650


Differences on label markings in print and old vs new version of model labels are as below (NMP1K2 Series for example):


Label markings in print

Before


After : add +, - symbols and color blocks to the right side in each bracket



Model labels

Old version

New version
